Wearable sensors styled into t-shirts and face masks

[Oct 19, 2022: Caroline Brogan, Imperial College London]


People can achieve long-term health goals and establish healthy habits. (Credit: Creative Commons)


Wearable sensors styled into t-shirts and face masks


Imperial researchers have embedded new low-cost sensors that monitor breathing, heart rate, and ammonia into t-shirts and face masks.


Potential applications range from monitoring exercise, sleep, and stress to diagnosing and monitoring disease through breath and vital signs.





Spun from a new Imperial-developed cotton-based conductive thread called PECOTEX, the sensors cost little to manufacture. Just $0.15 produces a metre of thread to seamlessly integrate more than ten sensors into clothing, and PECOTEX is compatible with industry-standard computerised embroidery machines.


First author of the research Fahad Alshabouna, PhD candidate at Imperial’s Department of Bioengineering, said: “The flexible medium of clothing means our sensors have a wide range of applications. They’re also relatively easy to produce which means we could scale up manufacturing and usher in a new generation of wearables in clothing.”




Related Stories:



The research team embroidered the sensors into a face mask to monitor breathing, a t-shirt to monitor heart activity, and textiles to monitor gases like ammonia, a component of the breath that can be used to track liver and kidney function. The ammonia sensors were developed to test whether gas sensors could also be manufactured using embroidery.


Fahad added: “We demonstrated applications in monitoring cardiac activity and breathing, and sensing gases. Future potential applications include diagnosing and monitoring disease and treatment, monitoring the body during exercise, sleep, and stress, and use in batteries, heaters, anti-static clothing."


The research is published today in Materials Today.





Seamless sensors


Wearable sensors, like those on smartwatches, let us continuously monitor our health and wellbeing non-invasively. Until now, however, there has been a lack of suitable conductive threads, which explains why wearable sensors seamlessly integrated into in clothing aren’t yet widely available.


Synthesis of PECOTEX and a photograph of the produced thread on a bobbin. Inset shows the chemical structure of the product; (b) Process for computerised embroidery of patterns using PECOTEX and 1 mm thick silicone substrates. (CREDIT: Materials Today)


Enter PECOTEX. Developed and spun into sensors by Imperial researchers, the material is machine washable, and is less breakable and more electrically conductive than commercially available silver-based conductive threads, meaning more layers can be added for to create complex types of sensor.





Lead author Dr Firat Guder, also of the Department of Bioengineering, said: “PECOTEX is high-performing, strong, and adaptable to different needs. It’s readily scalable, meaning we can produce large volumes inexpensively using both domestic and industrial computerised embroidery machines.


via GIPHY, Credit: Guder Research Group


“Our research opens up exciting possibilities for wearable sensors in everyday clothing. By monitoring breathing, heart rate, and gases, they can already be seamlessly integrated, and might even be able to help diagnose and monitor treatments of disease in the future.”





Next, the researchers will explore new application areas like energy storage, energy harvesting and biochemical sensing, as well as finding partners for commercialisation.



This study was funded by the Saudi Ministry of Education, Engineering and Physical Sciences Research Council (EPSRC, part of the UKRI), Cytiva, Imperial’s Department of Bioengineering, Bill and Melinda Gates Foundation, and the US Army.





"PEDOT:PSS-modified cotton conductive thread for mass manufacturing of textile-based electrical wearable sensors by computerized embroidery" by Alshabouna et al., published in Materials Today.





For more science and technology stories check out our New Innovations section at The Brighter Side of News.




Note: Materials provided above by Imperial College London. Content may be edited for style and length.
