Researchers demonstrate fundamentally new approach to ultrasound imaging
[Aug. 13, 2020: NC State University]
North Carolina State University researchers have demonstrated a new technique for creating ultrasound images. The new approach is substantially simpler than existing techniques and could significantly drive down technology costs.
"Conventional ultrasound devices have a receiver that detects ultrasonic waves and converts them into an electrical signal, which is then sent to a computer that processes the signal and converts it into an image," says Xiaoning Jiang, co-corresponding author of a paper on the work and a Duncan Distinguished Professor of Mechanical and Aerospace Engineering at NC State. "We've created a device that effectively eliminates the electrical signal processing altogether."
Specifically, the researchers have developed a receiver that incorporates a piezoelectric crystal and an organic light-emitting diode (OLED). When an ultrasonic wave hits the crystal, it produces voltage, which causes the OLED to light up. In other words, the image appears on the OLED screen, which is built into the receiver itself.
"Our prototype is a proof-of-concept, so we designed it with an OLED array that is 10 pixels by 10 pixels; the resolution isn't great," says Franky So, co-corresponding author of the study. "However, I can easily make it 500 pixels by 500 pixels, boosting the resolution substantially." So is the Walter and Ida Freeman Distinguished Professor of Materials Science and Engineering at NC State.
Like these kind of stories? Get The Brighter Side of News' newsletter.
"Conventional ultrasound imaging probes can cost upward of $100,000 because they contain thousands of transducer array elements, which drives up manufacturing costs," So says. "We can make ultrasound receiver-display units for $100 or so."
"This is really a completely new field for ultrasound, so we're only beginning to explore the potential applications," Jiang says. "However, there are obvious near-term applications, such as non-destructive testing, evaluation and inspections in the context of structural health monitoring."
The researchers are interested in collaborating with industry partners to explore commercial applications.
The paper, "Direct Acoustic Imaging using a Piezoelectric Organic Light-Emitting Diode," is published in ACS Applied Materials & Interfaces. First author of the paper is Hyeonggeun Yu, a former postdoctoral researcher at NC State who is now at the Korea Institute of Science and Technology. The paper was co-authored by Jinwook Kim and Howuk Kim, who are former Ph.D. students at NC State; and by Nilesh Barange, a former postdoctoral researcher at NC State.
Note to Editors: The study abstract follows.
"Direct Acoustic Imaging using a Piezoelectric Organic Light-Emitting Diode"
Authors: Hyeonggeun Yu, Jinwook Kim, Howuk Kim, Nilesh Barange, Xiaoning Jiang, and Franky So, North Carolina State University
Published: July 22, 2020, ACS Applied Materials & Interfaces
Abstract: Conventional ultrasonic imaging requires acoustic scanning over a target object using a piezoelectric transducer array, followed by signal processing to reconstruct the image. Here, we report a novel ultrasonic imaging device that can optically display an acoustic signal on the surface of a piezoelectric transducer. By fabricating an organic light-emitting diode (OLED) on top of a piezoelectric crystal (lead zirconate titanate, PZT), an acousto-optical piezoelectric OLED (p-OLED) transducer is realized, converting an acoustic wave profile directly to an optical image. Due to the integrated device architecture, the resulting p-OLED features a high acousto-optic conversion efficiency at the resonant ultrasound frequency, providing a piezoelectric field to drive the OLED. By incorporating an electrode array in the p-OLED, we demonstrate a novel tomographic ultrasound imaging device that is operated without a need for conventional signal processing.
